Factory direct sale wholesale price solar panel energy system on off grid complet 5kw mppt solar hybrid inverter

❖ General mode:

A photovoltaic energy storage system serves as the energy conversion and control center for the entire household photovoltaic system. Its primary function is to convert unstable photovoltaic power into stable AC power for household loads, and to store excess energy in energy storage batteries.

❖ Description:

❖ Solar Panel
Solar modules convert light energy into DC electrical energy by means of the photovoltaic effect. And it’s the energy source of entire system

❖ Utility Grid(AC Input)
The mains electricity or generator can be used as an energy supplement to the PV system,charging the batteries or supplying the load when there is a lack of solar energy, and some models support the feeding of excess power back into the grid.
❖ Battery
Batteries are used to store energy,for example to store photovoltaic energy generated during the day for use at night, or to provide emergency power for households in the event of a mains power failure.
❖ Home Load(AC Output)
For electrical equipment throughout the home, please select the appropriate model according to the power used.

Model	LY3024ML	LY3024MH	LY5048MH	LY10048MH
Battery Input Data
Battery Type	Lithium-ion/Lead Aid Battery/Gel Battery/Deep Cycle battery
Battery Voltage Range (V)	24V	24V	48V	48V
Constant Charging Voltage (V)	28.2v	28.2V	56.4V	56.4V
Float charging Voltage(V)	27V	27V	54V	54V
AC Input Voltage
Input Formation	L+N+PE
AC Input	208/220/230/240VDC
Input Voltage Range	154-264VAC±3V(Normal mode)185-264VAC±3V (ups mode)
Frequency	50/60HZ(Adaptive)
Output
Rated Power	3kw	3kw	5kw	10kw
Output Voltage	208/220/230/240VDC±5%
Output Frequency	50/60hz±0.1%
Output Wave	Pure Sine Wave
Transfer Time(Adjustable)	10ms for computer equipment,20ms for household euipment
Peak Power	6kva	6kva	10kva	15kva
Overload Ability	Battery Mode:1min@102% load 10s@110%-130% load 3s@130%-150%load 200ms@>150% load
Peak Efficiency(Battery Mode)	>94%
Charger
PV Charging Method	MPPT
Max PV Input	1500W	4000W	5500W	1100W
MPPT Tracking Range	30~145VDC	120~500VDC	120~500VDC	120~500VDC
Best Vmp Working Range	30~115VDC	300~400VDC	300~400VDC	300~400VDC
Max PV Input Voltage	150VDC	500VDC	500VDC	500VDC
Max PV Charge Current	60A	100A	100A	100A
Max AC Charge Current	60A	60A	100A	100A
Max Charge Current	120A	100A	100A	100A
Display(LCD)	Can display operating mode/load/input/output
Communication Port	RS232			5PIN/Pitch2.54mm,Baud Rate 2400
		Expansion slot communication interface			WIFI 2*5PIN/Pitch2.54mm,Lithium Battery BMS Communication Card
Parallel Interface	NO	NO	Support	Support
Ambient Temperature
Operating Temperature	0℃~40℃
Storage Temperature	-15℃~60℃
Ork Altitude	No more than 1000m,if <1000m,rate power will lower,max 4000m,refer IEC62040 TO IEC62040
Operating Environment Humidity	20%~95% Non condensing
Noise	<50db
Deimension(L*W*H)	495*312*125MM
Standard&Certificate	EN-IEC 60335-1,EN-IEC 60335-2-29,IEC62109-1

❖ Feature

* PF1.0,High effiency,lower consumption,energy conservation,Environmental Protection,Electricity Saving,Cost Saving.
* Support working without battery,reduce solar system cost.
* Parallel function up to maximum 9 units,enlarge more loads.
* High precision of output voltage,+5%,take care of your appliances.
* Communication Option:External WIFI,Supervise at any time.

❖ Protection

* Lithium Battery Auto-restart function,more convenient for lithium battery charging.

* Intelligent Power Supply mode,intelliget distribution of solar panel/Mains/Battery Power shares.

* Utility charging voltage/pv charing voltage adjustable,match different battery charging requirement.

❖ Function

*Slim Body,convenient installation&transportation.

*Battery Reverse Connection Protection with Fuse Switch,safer Installation.

❖ OEM&ODM

*OEM

The logo can be print on the inverter when the quantity is more than 20pcs with free.

*ODM

The color ,the materials and the pattern will be modify by us if your quantity is more than 50pcs with free.

❖ Button Specification

❖ Project

The home hybrid soar system is mainly suitable for applications where the power grid is unstable and there is an important load, or the photovoltaic self-use can not fed to the grid, the self-use price is much more expensive than the on-grid price, and the wave peak price is much more
expensive than the wave flat price.

❖ Company

The company has been committed to customer requirement as a guide to achieve win -win cooperation since its establishment.We are focus on the on grid solar system ,off grid solar system ,hybrid solar system of home use and Commercial solar system .All your requirement can contact us directly, we can provide the pre-sale service,quotation and after service,warmly welcome your come!

❖ Quality gurantee

The solar panel should be implement the strict quality control,such as Glass uplifting,EVA Slitting,IV test,Cleaning and so on.For that,the quality can be higher guarantee.

❖ Plywood Package

The on grid solar system ,off grid solar system and hybrid solar system will be packaged with plywood Case in order to avoid the damage from the transportation.Any special requirement about the package,pls advice us in advance!

❖ Certificate

1.The solar panel will past the certificate ,such as ISO,TUV,IEC,BIS ,CQC.

2.The solar inverter certificate is depend on the
different brand,the accurate certificate will be provided by us if you can contact with us directy.

FAQ

1.What kind of product can you provide ?
Re:We can provide the solar energy system such as on grid solar system,off grid solar system and hybrid solar system.They are including the solar panel,solar inverter,PV combiner box,battery,mounting system and installation tools.

2.How much power energy can your company provide?
Re:We can provide the home use solar system from 5kw to 20kw and also provide the commercial solar system from 20kw to 500kw with excellent design.

3.Who is your service customer?
Re:Individual client for house solar systems; distributor; importer and solar energy system installer.

4.What is your warranty and after-sales policy?
Re:Warranty term: the lower price PV solar inverter is 1 years old.

5.How many days will the product delivery?
Re:All the sample package will shipped within 7 working days after your payment.the bulk order will be dispatched with 14 working days after your payment.
