    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    Ask Lasest Price
    Brand Name : Deye
    Model Number : SUN-35K-SG01HP3
    Supply Ability : 10 Carton/Cartons per Day
    Price : $4,927.00/watts 1-4 watts
    • Product Details
    • Company Profile

    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    ❖ General mode:

    Commercial hybrid solar system will be used on the framland,residential community ,bus station,factory ,car parking and large ground power station.Deye full series inverter products support remotely shutdown immediately when accident occurs.Setting parameters and FW update remotely, which makes PV plant O&M easier.
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    ❖ Description:
    Deye hybrid solar inverter is brand new three phase hybrid inverter with High voltage battery 160-800V, ensuring system efficiency and less heat dissipation.With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment. It supports three phase unbalanced output, extending the application scenarios.
    Model
    SUN-30K-SG01HP3
    SUN-35K-SG01HP3
    SUN-40K-SG01HP3

    SUN-50K-SG01HP3
    Battery Input Data
    Battery Type
    Lithium-ion
    Battery Voltage Range (V)
    160~800
    Max. Charging Current (A)
    50+50
    Max. Discharging Current (A)
    50+50
    Number of battery input
    2
    Charging Strategy for Li-Ion Battery
    Self-adaption to BMS
    PV String Input Data
    Max. DC Input Power (W)
    39000
    45500
    52000
    65000
    Max. DC Input Voltage (V)
    1000
    Start-up Voltage (V)
    180
    MPPT Range (V)
    150-850
    Full Load DC Voltage Range (V)
    360-850
    Rated DC Input Voltage (V)
    600
    PV Input Current (A)
    36+36+36
    Max. PV I (A)
    55+55+55
    No.of MPP Trackers
    3
    4
    4
    4
    No.of Strings per MPP Tracker
    2
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    Feature
    * 100% unbalanced output;each phase
    * AC couple to retrofifit existing solar system
    * Max. 10 pcs parallel for on-grid and off-grid
    operation; Support multiple batteries parallel
    * Max. charging/discharging current of 100A
    * High voltage battery, higher efficiency
    * 6 time periods for battery charging/discharging
    * Support storing energy from diesel generator
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter



    Protection

    * Anti-islanding Protection, PV String Input Reverse Polarity Protection。

    * Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection。

    *Output Shorted Protection, Surge Protection
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    ❖ AC Output Data

    * Rated AC Output and UPS Power (W):30kw/35kw/40kw/50kw
    * Max. AC Output Power (W):33kw/38.5kw/44kw/55kw
    * Peak Power (offff grid):1.5 time of rated power, 10 S
    * Power Factor:0.8 leading to 0.8 lagging
    * Output Frequency and Voltage:50/60Hz; 3L/N/PE 220/380, 230/400Vac
    * Grid Type:Three Phase
    * Total Harmonic Distortion (THD):<3% (of nominal power)
    * DC current injection:<0.5% In

    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    ❖ Function

    * Max. Effiffifficiency:97.60%
    * Safety EMC / Standard:IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
    * Operating Temperature Range (℃):-40~60℃, >45℃ derating
    * Cooling:Smart cooling
    * Communication with BMS:RS485; CAN
    * Weight (kg):75kg
    * Size (mm):527×894×294
    * Protection Degree:IP65
    * Installation Style:Wall-mounted
    * Warranty:5 years

    ❖ Project


    The home hybrid soar system is mainly suitable for applications where the power grid is unstable and there is an important load, or the photovoltaic self-use can not fed to the grid, the self-use price is much more expensive than the on-grid price, and the wave peak price is much more
    expensive than the wave flat price.
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    Exhibition
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    ❖ Company

    The company has been committed to customer requirement as a guide to achieve win -win cooperation since its establishment.We are focus on the on grid solar system ,off grid solar system ,hybrid solar system of home use and Commercial solar system .All your requirement can contact us directly, we can provide the pre-sale service,quotation and after service,warmly welcome your come!
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    ❖ Quality gurantee

    The solar panel should be implement the strict quality control,such as Glass uplifting,EVA Slitting,IV test,Cleaning and so on.For that,the quality can be higher guarantee.
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    ❖ Plywood Package


    The on grid solar system ,off grid solar system and hybrid solar system will be packaged with plywood Case in order to avoid the damage from the transportation.Any special requirement about the package,pls advice us in advance!
    Manufacturers china high quality three phase mppt photovoltaic solar inverter 35kw hybrid on off grid solar inverter

    ❖ Certificate


    1.The solar panel will past the certificate ,such as ISO,TUV,IEC,BIS ,CQC.
    2.The solar inverter certificate is depend on the
    different brand,the accurate certificate will be provided by us if you can contact with us directy.
    FAQ
    1.What kind of product can you provide ?
    Re:We can provide the solar energy system such as on grid solar system,off grid solar system and hybrid solar system.They are
    including the solar panel,solar inverter,PV combiner box,battery,mounting system and installation tools.

    2.How much power energy can your company provide?
    Re:We can provide the home use solar system from 5kw to 20kw and also provide the commercial solar system from 20kw to 500kw with excellent design.

    3.Who is your service customer?
    Re:Individual client for house solar systems; distributor; importer and solar energy system installer.

    4.What is your warranty and after-sales policy?
    Re:Warranty term: PV panel, cable, mounting frame for 15 years, Inverter for 1-3 years, battery for 5 years. Any quality
    problem,will let us freely.

    5.How many days will the product delivery?
    Re:All the package will shipped within 10~20 working days after your payment.
