    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System

    Ask Lasest Price
    Brand Name : zzlysun
    Model Number : 10kw/12kw/15kw on grid
    Supply Ability : 10 Carton/Cartons per Day
    Price : $0.65/watts 10000-49999 watts
    • Product Details
    • Company Profile

    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System

    Top supplier high efficiency wholesale price full solar power home use 10kw solar system pv system on grid

    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    General mode:
    Home on grid solar system is the power from PV Array will be provided by the load,the excess electric can be fed to the grid,it is suitable for the country which the local grid is stability.
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    Product List
    10kw on grid solar
    12kw on grid solar
    15kw on grid solar
    PV module
    455w*26pcs
    455w*28pcs
    455w*33pcs
    PV combiner box
    2 Input 2 output
    2 Input 2 output
    2 Input 2 output
    Inverter
    Growatt on grid 10kw
    Growatt on grid 12kw
    Growatt on grid 12kw
    Monitor
    Wifi Module
    Wifi Module
    Wifi Module
    Battery
    No
    No
    No
    Mounting System
    Roof mounting/Ground mounting (Design by your requirement)
    Accessories
    MC4 Connector,PV cable,Installations
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ Solar Panel
    1.Power:445~470W
    2.The quantity of Cell:144PCS
    3.Solar cells size:166*83mm
    4.Dimensions:2094x1038x35mm(LxWx H)
    5.Open Circuit Voltage-Voc[V]:49.56V
    6.Short Circuit Current-lsc[A]:11.32A
    7.Max Power Voltage-Vmp[V]:41.21V
    8.Max Power Current-lmp[A]:10.08A
    9.Module Efficiency:20.47%
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ On Grid Solar Inverter
    1. Rate Power: 10KW/12KW/15kw
    2. MPP voltage range:180V-850V
    3. AC Voltage Regulation:400, 3L/N/PE
    4. AC grid frequency:50Hz/60Hz
    5. Max. Short Circuit Current per MPPT (A):15.6KW/31.2KW
    6. MPPT Efficiency :98.2%
    7. AC grid connection type:3W+N+PE
    8. Nominal voltage:620V
    9. No. of MPP trackers:2pcs
    10. Max. input current per MPP tracker:12.5A
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ Accessories
    1. PV Combiner Box
    (Anti-reverse/SPD/Fuse/Busbar
    /Breaker 63A1000V)

    2. MC4 Connector
    Rated current: 30A Rated voltage: 1000VDC

    3. PV DC Cable
    4mm2 or 6mm2

    4. Installation tolls
    Wire Crimper, Stripper, MC4 Connector Wrench
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ Mounting Bracket
    1. Good Appearance
    2.Easy and flexible installation.
    3.Diversified design
    4.Light dead-weight
    5.Save installation materials
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    Advantage
    The home on grid soar system are suitable for the country,which are the payment bill is expensive .It can save the pay bill without the battery investment ,the excess electric can fed to the grid for earnings.
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ Company
    The company has been committed to customer requirement as a guide to achieve win -win cooperation since its establishment.We are focus on the on grid solar system ,off grid solar system ,hybrid solar system of home use and Commercial solar system .All your requirement can contact us directly, we can provide the pre-sale service,quotation and after service,warmly welcome your come!
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ Quality gurantee
    The solar panel should be implement the strict quality control,such as Glass uplifting,EVA Slitting,IV test,Cleaning and so on.For that,the quality can be higher guarantee.
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ Plywood Package
    The on grid solar system ,off grid solar system and hybrid solar system will be packaged with plywood Case in order to avoid the damage from the transportation.Any special requirement about the package,pls advice us in advance!
    Home Use On Grid Solar Energy System 10KW PV MPPT Controller System
    ❖ Certificate
    1.The solar panel will past the certificate ,such as ISO,TUV,IEC,BIS ,CQC.
    2.The solar inverter certificate is depend on the different brand,the accurate certificate will be provided by us if you can contact with us directy.
    FAQ
    1.What kind of product can you provide ?
    Re:We can provide the solar energy system such as on grid solar system,off grid solar system and hybrid solar system.They are including the solar panel,solar inverter,PV combiner box,battery,mounting system and installation tools.

    2.How much power energy can your company provide?
    Re:We can provide the home use solar system from 5kw to 20kw and also provide the commercial solar system from 20kw to 500kw with excellent design.

    3.Who is your service customer?
    Re:Individual client for house solar systems; distributor; importer and solar energy system installer.

    4.What is your warranty and after-sales policy?
    Re:Warranty term: PV panel, cable, mounting frame for 15 years, Inverter for 1-3 years, battery for 5 years. Any quality problem,will let us freely.

    5.How many days will the product delivery?
    Re:All the package will shipped within 10~20 working days after your payment.
